Proteus 8.5 - Introducing Visual Designer
Version 8.5 is an interim release in the PCB development schedule and features a complete re-working of the CADCAM output engine. The RS274X output has been upgraded to make full use contours and polygonal apertures whilst the new code can also generate the latest Gerber X2 format as well as an IPC-D-356 bare board netlist.
Other features added are significant improvements to the large pin count BGA workflow which are included in the release of 8.5 SP0. Meanwhile, our major development focus on 'push-and-shove manual routing' remains on target for the end of the year.
8.5 also sees the introduction of Visual Designer for Arduino AVR - a flowchart based programming environment for the Arduino ecosystem that makes full use of the simulation capabilities of Proteus VSM.
A full list of features and fixes is available from the Updates and Fixes Support Forum. Proteus 8.5 is available free of charge to all customers whose USC is valid as of 1st June 2016.
